Project

Customer : Panel Plus MDF Co.,Ltd.
(Songkhla Province)

PROJECT MDF: BELT CONVEYOR
SCOPE OF WORK : DESIGN FABICATION AND INSTALLATION.
CAPACITY : - TON/HR.
   1. TUBE BELT CONVEYOR  (TRANSFER WOOD CHIPS) : W800 MM. x L28,5000 MM. CAP 505 CMH.
   2. TUBE BELT CONVEYOR (TRANSFER WOOD CHIPS) : W800 MM. x L67,000 MM. CAP 505 CMH.
   3. TROUGH BELT CONVEYOR – MOAVBLE – REVERSOBLE (TRANSFER WOOD CHIPS) : W1,200 MM. x L14,500MM. CAP 505 CMH.
   4. TROUGH BELT CONVEYOR (TRANSFER BARKS) : W800 MM. x L40,000 MM. CAP 100 CMH.
   5. TUBE BELT CONVEYOR (TRANSFER BARKS) : W500 MM. x L44,500 MM. CAP 100 CMH.
   6. TROUGH BELT CONVEYOR (TRANSFER BARKS) : W800 MM. x L8,000 MM. CAP 100 CMH.
   7. TUBE BELT CONVEYOR (TRANSFER BARKS) : W500 MM. x L 43,000 MM. CAP 100 CMH.
   8. TUBE BELT CONVEYOR (TRANSFER BARKS) : W500 MM. x L65,000 MM. CAP 220 CMH.
   9. TROUGH BELT CONVEYOR (TRANSFER WOOD CHIPS) : W800 MM. x L30,700 MM. CAP 25 CMH.
   10. TROGH BELT CONVEYOR (TRANSFER WOOD CHIPS) : W800 MM. x L32,000 MM. CAP 200 CMH.
   11. TUBE BELT CONVEYOR (TRANSFER BARKS) : W500 MM. x L62,250 MM. CAP 200 CMH.
   12. FULE BELT CONVEYOR (TRANSFER FULE MATERIALS) : W1,000 MM. x L64,000 MM. CAP 95 CMH.
   "ALL MACHINE INCLUDE STEEL STRUCTURE COLUMN + PLATEFORM + WALKWAY + HANDRAIL + LADDER FOR BELT CONVEYOR."
